Why A&K for Bearings

Bore, Bolt Pattern, Shaft Fit — Right the First Time

Bearing supports are the wear item that gets replaced most often on every belt and chain conveyor. The problem isn't sourcing the bearing insert — that's commodity. The problem is the housing: when the bolt pattern is wrong by ¼", or the bore is one shaft size off, or the OEM housing has been discontinued, the bearing won't go in.

A&K machines pillow blocks, take-up units, flange mounts, and custom housings to whatever spec your frame needs. Bore, bolt pattern, and shaft fit are all on the drawing — and out of the machine right the first time.

2- and 4-bolt pillow blocks, 2/3/4-bolt round and square flange housings

Take-up housings — wide-slot (WSTU) and narrow-slot (NSTU), center-pull and top-angle (TUE/TUT) frames

Built to ISO 113 / ANSI/ABMA 8.2 — drop-in interchange for Dodge USAF/USN/SAF-XT/ISN, SKF SN/SNL/SAF, Sealmaster MP/NP, Browning VPS/VPLS, Timken Type E

Cast iron, carbon steel, or stainless 304/316 — sized to the bearing-insert spec you already source

Seal pockets cut for taconite (purgeable), triple-lip (TripleTect), labyrinth (LER), or contact-lip washdown

Custom housings for legacy frames where the OEM part has been discontinued

Machined bearing hub housings with through-bores in the A&K shop — A&K Machine & Fabrication, Jacksonville FL

Housing Types

Every Mount, Every Shaft

Pillow Block Housings

2- and 4-bolt pillow blocks for shaft-end and intermediate support. Crosses Dodge USAF/USN, Sealmaster MP/NP, Browning VPS/VPLS, Timken Type E. Cast iron for standard service, carbon steel for heavier loads, stainless for wet or corrosive.

Take-Up Bearing Units

Wide-slot (WSTU) and narrow-slot (NSTU), center-pull and top-angle (TUE/TUT) frames. Slotted housings sized to ABMA standard envelopes — drop-in retrofit for Dodge, Sealmaster, and Browning take-up frames.

Flange-Mount Bearings

2-, 3-, and 4-bolt round and square flange housings per ANSI/ABMA 8.2. Bore machined to your bearing-insert tolerance; seal pockets matched to the service environment.

Split Plummer Blocks

Split SN/SNL series (2/3/5/6 and 30/31/32), SAF/USAF, and SDAF/SAFD for large bore — for shafting where pull-and-replace isn't practical. Machined split lines for clean reassembly; bored for spherical-roller inserts.

Insert Bearing Housings

Cartridge-mount housings for OEM-style assemblies — bored bearing pocket, integrated seal seats, and your choice of locking method (setscrew, eccentric collar, or adapter sleeve).

Custom & Hybrid Housings

When standard housings don't fit and OEM is discontinued, we machine to print. Hybrid mountings, integrated mounting bosses, custom inspection ports — whatever your frame needs.

Bronze and brass bushings boxed and labeled ready for shipment — A&K Machine & Fabrication, Jacksonville FL

Materials & Sealing

Match the Housing to the Environment

Most bearing housings don't fail from load — they fail when contamination gets past the seal. Picking the right material and sealing strategy for your environment is half of getting service life right.

Cast iron: Workhorse material — dimensional stability, vibration damping.
Carbon steel: Higher impact strength, weldable, fabricated assemblies.
Stainless 304 / 316: Food, marine, washdown, chemical service. PBT thermoplastic housings on request for full IP69K washdown.
Felt / single-lip seals: Clean, dry, indoor — low speed.
Labyrinth (LER): High-speed clean service with light dust — non-contact, no drag.
Triple-lip (TripleTect): Wet, abrasive, heavy contamination — contacting elastomer lips on a flinger.
Taconite (purgeable): Mining, aggregate, cement, kiln duty. Auxiliary grease purge groove pushes contamination back out before it reaches the bearing — the named industry standard for the worst environments.
Contact-lip washdown (IP69K): Food and dairy plants. Paired with USDA H1 grease and end caps; 3-A Dairy compliance on request.
Internal clearance: C0/CN normal; C3 default for conveyors with thermal rise; C4 for hot/heavy duty (kilns, dryer drums).

Our Process

From Worn Housing to New Housing

Spec

Send the worn housing, the bearing-insert part number, or your frame bolt pattern. We confirm bore, OAL, and mount geometry.

Quote & Source

Fixed quote, real lead time. Casting blanks or bar stock sourced same-day; bearing inserts can be supplied or you keep your existing supply.

Machine & Assemble

CNC-bore, mount holes drilled and tapped, seal pockets cut to tolerance. Bearing pressed in if requested, sealed and palletized.

Ship or Install

Shipped to your dock or installed on-site during your scheduled outage by our service crew.

Industries

Who We Supply Bearing Housings To

Mining & Aggregates Agriculture Food & Beverage Pharmaceuticals Wood, Pulp & Paper Recycling Wastewater Distribution & Warehouse Marine Power & Utilities Airports Construction & Roads

Common Questions

Bearing Housing FAQ

Can A&K machine a housing for a bearing I already have?

Yes — supply the bearing insert (or the part number) and we'll machine the housing to the exact bore + seat tolerance for that insert. You keep your existing bearing supply chain; we just fix the housing problem.

My OEM pillow block is discontinued. Can you match it?

Yes — this is one of our most common requests. Send the worn original (or just the bolt pattern and bore), and we reverse-engineer a drop-in replacement. We can even match the OEM paint color if you need it to look identical.

Cast iron vs steel housings — which should I pick?

Cast iron is the default — dimensionally stable, dampens vibration, good for typical loads. Choose steel when impact is part of the duty cycle (e.g. mining transfer chutes) or when you need a weldment configuration. Stainless when corrosion is the failure mode.

Do you press the bearing insert in or leave it for the customer?

Either way works — tell us your preference. Pressing in shop saves you a step and ensures clean seal seating; leaving it open lets you use your own bearing stock and install supervision.

Do you cut taconite seal pockets for mining and aggregate?

Yes — auxiliary purge groove plus felt cartridge to the OEM envelope. Taconite is the standard ask for crusher feed, cement, and any environment where dust and fines are constant; the grease purge keeps contamination from ever reaching the bearing race.

Setscrew, eccentric collar, or adapter sleeve — which locking should I spec?

Setscrew for light loads and low cost — but it dimples the shaft and is uni-directional under heavy reversal. Eccentric collar for one-direction drives with better grip. Concentric clamp collar when bi-directional + even contact matter. Adapter sleeve for high speed and zero shaft cocking.

Spherical roller or self-aligning ball insert?

Self-aligning ball for cleaner, lighter, faster service (general conveyor). Spherical roller for heavy loads, shock duty, and ±2° misalignment — head pulleys on aggregate, crushers, and anything that takes a hit at the load point.

How fast can you turn around a custom bearing housing?

Standard pillow block or flange housings: usually 3-7 business days. Custom or unusual configurations: 1-2 weeks for material + machining. Call 904-388-7772 with the spec and we'll give you a real lead time before you commit.
